MVS50 X: the reliable and easy-to-use wheeled vacuum packaging machine

With the MVS X vacuum chamber packaging machine range, minipack®-torre offers a series of machines with high-quality technologies and functions, while maintaining the maximum ease of use that has always characterized the company’s products. One of the greatest strengths of these machines is undoubtedly their high compatibility with all vacuum food packaging requirements, achieved thanks to collaboration with leading chefs and professional operators, who helped enrich the equipment of the packaging machines with new specific functions.

Thanks to a touch-control keyboard hermetically bonded to the front body of the machine, the board is protected against any infiltration; the control display allows up to 10 different customized programs to be set, designed to cover all vacuum packaging needs in the food sector.

In addition, these vacuum chamber machines can read, through a dedicated sensor, the vacuum level created in the chamber; a message is displayed whenever an oil change is required. Another requirement fulfilled is setting the packaging machine according to the altitude at which it must operate, in order to calibrate it to the atmospheric pressure of the location.



TECHNICAL FEATURES:

  • Stainless steel (AISI 304)
  • Vacuum cycle with stop
  • Bag scrap trimming device
  • Quick-release aluminum sealing bar
  • Transparent lid made of food-grade plastic material
  • Volumetric sensor for vacuum detection
  • PE-HD filling plates
  • 10 customizable programs
  • Self-calibration
  • Sealing bar overload safety
  • Oil and service warning light
  • CE – ETL – NSF certification.

Do you want to package your products with this machine?

The test is free and without obligation

Technical Data

Power supply
208V 60Hz 3Ph
220V 60Hz 1Ph
400V 50Hz 3Ph
Maximum installed power
3,6 kW (208V 60Hz)
3,8 kW (220V 60Hz)
1,8 kW (400V 50Hz)
Maximum electrical absorption
14 A (208V 60Hz)
17 A (220V 60Hz)
5,0 A (400V 50Hz)
Worktop height889 mm
Vacuum pump40 m³
Sealing bar dimensions510 mm (nr. 2)
Usable chamber dimensions (tank + lid)562x518 h.241 mm
Machine dimensions (lid open)773x758 h.1313 mm
Machine dimensions (lid closed)773x758 h.1028 mm
Machine weight (net/gross)180/205 kg
